| Hardware Specifications | |
| Interface |
LAN RJ45 Port (FE) * 1;
DC Socket;
SIM Slot * 1;
|
| Indicators |
1. Power/Battery
2. Wi-Fi Switch
3. LTE Network
4.Signal Strength
|
|
Buttons
|
POWER On/Off Button
WPS Button
RESET Button
Wi-Fi Button
|
| SIM |
Micro SIM(3FF)
Support 1.8V & 3.3V
|
|
Power Consumption
|
< 6 W
|
|
Charger (Optional)
|
AC: 100V~240V
DC: 12V/0.5A
|
| Dimensions | 135x142x62(mm) |
| RF Specifications | |
|
Supported Bands
|
LTE FDD:
B1/2/3/4/5/7/8/28
B1/2/3/4/5/7/8/20(Optional)
LTE TDD: B38/40/41
HSPA+/HSPA/UMTS: B1(2100MHz)/B2(1900MHz)/B5(850MHz)/B9(900MHz)
GSM: 850MHz/900MHz/1800MHz/1900MHz
|
| LTE MIMO |
MIMO 2*2(1TX 2RX)
|
| LTE Tx |
1 Tx |
|
LTE Output Power@25℃
|
22±2 dBm
|
| LTE Antenna |
2 Build-in Antennas |
| LTE Peak Throughput | DL 150 Mbps, UL 50 Mbps |
| Wi-Fi Frequency |
2.4Ghz |
| WiFi Output Power | 18 dBm/2.4G |
| Wi-Fi Antenna | 2 Built-in Antenna |
| Wi-Fi Antenna Gain | 3 dBi |
|
Wi-Fi Channel BW
|
20MHz, 40MHz
|
| Wi-Fi MIMO |
MIMO 2*2 (1T1R)
|
|
Wi-Fi Concurrent Users
|
32 |
| Software Specifications | |
User login
|
Support two users (user and admin) with different limitation and display |
|
SMS
|
Write/send/receive short messages
Send/receive extra-long messages
|
|
LTE Network Setup
|
Create/delete/edit APN
|
|
IPv4v6 dual stack
|
Support IPV4, IPV6, IPV4V6 |
|
Wi-Fi/WLAN Setup
|
SSID/Key,
SSID broadcasting and hiding,
Security Mode: None (Open),
WPA2-PSK(AES), and
WPA/WPA2-PSK(TKIP/AES)
WPS Setup,
Wi-Fi MAC Filter,
Wi-Fi Advanced Settings.
|
| DHCP Setup |
Enable/disable DHCP server
Configure DHCP IP Pool
Configure DHCP Lease Time
|
| DNS Setup |
Support the auto DNS or manual DNS configuration
|
| VPN | VPN PASSTHROUGHT |
| Cell lock |
Support |
| Carrier SIM Lock | Support |
| Backup/Restore | Encryption backup current settings and restore the backup settings |
| Diagnosis |
Export current diagnosis results and operation logs |
| Work mode | NAT/ Router mode |
File Name : Type: Size: Version:
Yeacomm YF-A10 Indoor 4G LTE C... PDF 639.75 KB
