Cellular Parameters

Frequency Band

Standard Version:

5G NR: N1/3/5/7/8/20/28/38/40/41/75/76/77/78

LTE FDD: B1/3/5/7/8/20/28/32

LTE TDD: B38/40/41/42/43

WCDMA : B1/5/8

Optional Version :

5G NR:N1/2/3/5/7/8/12/13/14/18/20/25/26/28/29/30/38/ 40/41/48/66/70/71/75/76/77/78/79

LTE-FDD: B1/2/3/4/5/7/8/12/13/14/17/18/19/20/25/26/ 28/29/30/32/66/71

LTD-TDD: B34/38/39/40/41/42/43/48

LAA:B46

WCDMA: B1/2/4/5/8/19

MIMO

5G NR: DL 4×4 MIMO,UL 2×2 MIMO

LTE: DL 4×4 MIMO

Theoretical Bandwidth

5G NR: DL 3.47Gbps,UL 900Mbps

LTE: DL 1.6Gbps (CAT19),UL 211Mbps (CAT18)

WIFI Parameters

WIFI Protocol

IEEE802.11 a/b/g/n/ac/ax (WIFI 6)

WIFI Frequency Band

2.4GHz+5GHz

Theoretical

Bandwidth

5GHz 4x4MIMO 11ax, 1.2Gbps

2.4GHz 4x4MIMO 11ax, 0.573Gbps

Channel Bandwidth

20MHz, 40MHz, 80MHz

Hardware

CPU

MTK7621 CPU@880MHz,Dual-core

5G Chipset

Qualcomm SDX62

Flash

128MB

DDR3

512MB

Software

Network Status

Signal strength

Network type(5G/4G)

SIM card status, Wi-Fi Status, LAN Status

System Status

Mobile parameters,

APN/DHCP/Wi-Fi information, Memory details,

Version/Device information

Internet Settings

Network mode setup,

Data switch,

Roaming setup

APN Setup

APN name,

Nat Switch on APN bear,

PDP(IPV4/IPV6/IPV4V6),

MTU size

SIM Card

PIN Management

SIM card Authentication

DHCP Setup

Enable/disable DHCP server Configure DHCP IP Pool Configure DHCP Lease Time

Static Route

Route Setup on WAN/LAN interface

DDNS

Support

Band Lock

Support

PCI Lock

Support

Cell Lock

Support

Carrier SIM Lock

Support

VPN

PPTP, L2TP, IPSEC, Wireguard, Zerotier
