*Support 2G/3G/4G net work connection
*Support network traffic statistics
*Built-in 8DBi antenna,enlarge the coverage area
*Support cell and band locking
*Support L2TP, PPPOE
*Support remote network management
*Support remote upgrade
|
Ccellular Specification
|
|
|
Frequency
|
FDD: B1/B2/B3/B5/B7/B8/B12/B17/B20, B4/B28 (Optional)
TDD Band 38/39/40/41
WCDMA: 900/2100Mhz, 850/900/1900/2100Mhz(Optional)
GSM: 850/900/1800/1900Mhz
Frequency can be customized according to your requirements
|
|
Speed(CAT4)
Max
|
FDD - LTE Downlink：150Mbps， Uplink：50Mbps
TDD-LTE: Downlink：150Mbps， Uplink：50Mbps
HSPA+: 42Mbps(download speed) 5.76Mbps(upload speed)
HSUPA: 5.76Mbps (upload speed)/ HSDPA:7.2Mbps(download speed:)
UMTS:384Kbps (download speed/upload speed)
|
|
Mainboard
|
|
|
Chipset model
|
ATHEROS 9341
|
|
Speed
|
533MHz
|
|
ROM
|
SDRAM：64MByte
FLASH ：8MByte
|
|
4G module
|
Embedded
|
|
Item
|
Content
|
|
Lan
|
1 x 10/100 Mbps Ethernet port(RJ45),
|
|
Indicator
|
"Power", "Sim", “ETH”, “Run” and “Signal”
|
|
Antenna
|
Cellular: high gain Internal 8DBi
|
|
SIM/UIM
|
Standard 3V/1.8V user card interface, 15KV ESD protection
|
|
Power
|
POE,through RJ45 port
|
|
Reset
|
Restore the router to its original factory default settings
|
|
Item
|
Content
|
|
Standard Power
|
Input：100V~240V, 50Hz~60Hz
Output:15V DC±10%
Output: 500mA
|
|
Power Range
|
5V---18V
|
|
Working temperature
|
-30～60℃
|
|
Storage temperature
|
-40～85℃
|
|
Humidity
|
≤95％
|
|
Dimension
|
252x112x58mm
|
|
weight
|
about 560g
|
|
Water proof and
dust proof
|
IP66
|
